There are two options:

Free?use

It contains a table with fixed conversion factors of nearly 100 gases. Registered users of Fluidat on the Net can use fluid data and/or conversion data provided by this facility in FLUICAL^?.

Licensed use

This?option includes the use of a dongle that gives access to the FLUIDAT^??database, allowing the user to easily calculate fluid data and/or conversion data for variable operating conditions.

Latest software release
Version: 1.36

Date: 2014-06-12

Main changes:
–?Added EL-FLOW Metal product series.
–?Added FLOW-SMS product series.
–?Added missing LOW-ΔP-FLOW models and set conversion method to LOW-ΔP.
–?Corrected sensor temperature offset for MASS-STREAM and MASS-VIEW product series.
–?Zeroing will not be performed for MASS-STREAM product series.
–?Fixed DUT flow calculation for certain combinations of reference and DUT instrument types.
–?Fixed % Rd accuracy margins calculation.

Other changes:
–?Clarified which fields are related to DUT and which to the REF.
–?Changed startup so Num lock will not be disabled.
–?BHTDDECom2 is tried to be registered when FLUICAL^??fails to create it.

Calibration Equipment

FLUICAL^??calibration software can be used in combination with any gas mass flow calibration device/system available. However, using Bronkhorst^??digital calibration equipment or reference instruments will reduce the time spent on manual data processing.
